MD Series mill discharge pumps Metso MIMICO NZ

Slurry Pump

MD Series Mill Discharge Pump

Max Flow

Up to 12,000 m³/h

Inlet Range

250-700 mm

Configuration

Rubber or Hard Metal
Heavy-duty slurry pump designed for grinding mill discharge in high-wear mineral processing environments.
View Brochure
Call Sales Support

Engineered for Tough Mill Discharge

The Metso MD Series is purpose-built for mill discharge duties in mineral processing. Available in metal (MDM) and rubber-lined (MDR) configurations, these pumps feature oversized shafts, thick casings, and reduced impeller overhang for long wear life and sustained hydraulic performance. With flow capacities up to 12,000 m³/h, they’re ideal for cyclone feeds and abrasive slurries. Compact and modular designs ensure easier maintenance and lower total cost of ownership.

MD Series Mill Discharge Pump Specifications

Max Flow CapacityUp to 12,000 m³/h
Inlet Size Range250–700 mm
ConfigurationRubber (MDR) or Metal (MDM)
Application TypeMill Discharge
Shaft MaterialOversized high-grade steel
Lining OptionsRubber or high-chrome alloy
Maintenance AccessOptional slide base
Mounting TypeHorizontal
Industry UseMining / Mineral Processing
Wear ProtectionExtra-thick casings and liners
Automation ReadyCompatible with control systems

Warranty: MIMICO offers warranty on all material processing equipment, with dynamic options to suit your needs. We also have servicing packages to keep your plants running smoothly. Get in touch with our sales support team to find the right solution for you.

Mill Duty Design

Built specifically for grinding circuit discharge, the MD Series withstands high abrasion and heavy solids loading without performance loss.

Lining Options

Choose between rubber-lined (MDR) and metal-lined (MDM) configurations to match your slurry type and wear profile.

Oversized Shaft

A large-diameter shaft reduces deflection and increases bearing life, enhancing reliability under heavy loads.

Slide Base Access

Optional maintenance slide base enables safe and efficient pump access, reducing downtime during liner and impeller changes.

Modular Components

Shared parts across models simplify inventory and maintenance, while supporting faster rebuilds in high-use operations.

High Flow Capacity

Flow rates up to 12,000 m³/h make the MD Series ideal for cyclone feed and other high-volume mineral processing tasks.
