Features
SolidBody concept
Integrates percussion mechanism and guide system into a single block of special cast iron, decrasing the total number of parts. It also eliminates components like damping and guiding elements and tie rods or stud bolts completely and results in an extremely slim and copmact shape to simplify handling. A replaceable piston liner supports low repair cost.
EnergyRecovery
The piston recoil energy is automatically utilized to increase the performance without additional hydraulic input and to lower vibrations.
Air and water inlet
To connect compressed air supply and an integrated water channel for dust suppression (for SB 152 – SB 1102, water nozzles as option).
ContiLube (TM) II and ContiLube (TM) II micro (optional)
Epiroc’s self-priming lubrication pump with adjustable grease volume, directly mounted on the hydraulic breaker, for uninterrupted operation and optimised lubrication. You can check the level of grease in the cartridge from the excavator cabin.
Floating bushing
Tool bushing with floating fit for easy exchange on-site with standard hand tools.
Pressure relief valve
Built-in valve to protect against overloads.
Dust wiper
Integrated dust wiper to extend service life of bushing and retainer bars.
AutoStart
The hydraulic breaker starts without load applied to working tool thus simplifying handling.
Patented tool locking system
Combining a lock buffer and solid pin for quick tool exchange.
Specifications
- Carrier weight class: 1.9 t – 4.5 t.
- Service weight: 140 kg.
- Working tool diameter: 50 mm.
- Working length of tool: 280 mm.
- Hydraulic input power, max: 11 kW.
- Oil flow: 25 l/min – 45 l/min.
- Operating pressure: 100 bar – 150 bar.
- Impact rate: 850 blows/min – 1 900 blows/min.
- Sound power level, guaranteed: 114 dB(A).
