Dynapac CA1500D roller

Single Drum Roller

Dynapac CA6500D Roller

Operating Mass

20,700kg

Static Linear Load

65 kg/cm

Compaction Width

2130 mm
The Dynapac CA6500D Roller is a high-capacity single-drum compactor tailored for the most demanding construction projects, including highways, dams, and industrial foundations. It handles challenging conditions with ease.

Maximum Performance for Demanding Jobs

The Dynapac CA6500D Roller is powered by a Cummins B4.5 engine and features a 2130 mm drum width, making it capable of compacting thick and dense materials efficiently. Its SEISMIC technology reduces the number of passes needed, saving fuel and time. With 65% gradeability and High Climb traction, it performs reliably on steep gradients. The spacious operator station provides excellent visibility and ergonomic controls for long shifts. Designed with durability and serviceability in mind, the CA6500D ensures high productivity and minimal downtime, making it ideal for the toughest applications.

Dynapac CA6500D Roller Specifications

Vibration Frequency29 / 30 Hz
Vertical Oscillation±9°
Speed Range4-11 km/h
EngineCummins B4.5 (Stage V / T4final)
Rated Power149 kW (200 hp) @ 2,200 rpm

Warranty: 1 year or 1500 Hours Dynaplus Extended Warranty Plans Available.

Maximum Power

Delivers unmatched performance for handling tough and large-scale compaction tasks.

Fuel Optimisation

Engineered to minimise fuel consumption and significantly lower emissions output.

Seismic Adaptation

Adjusts vibration frequency for efficient compaction on varying soil conditions.

Robust Design

Built to withstand the most demanding environments and daily challenges.

Operator Safety

The cab includes advanced safety features and prioritises operator comfort.

Maintenance Access

Quick and easy access to service points reduces downtime effectively.
