Applications
These small but powerful pavers are especially designed for reinstatement and construction works which require low working widths. Particularly job sites like cycle-tracks, side walks, pavement-extensions, car-parks and sport-fields are ideally suited for Dynapac mini-pavers.
Features
HIGH WEARING COMFORT
The adjustable shoulder straps give the operator the comfort needed to work ergonomically for a whole day. The RC 360 comes with a case, charging devices with machine connector, and for external supply.
HIGHEST SAFETY LEVEL
When the operator exceeds a distance of 10m, the paver stops. The paver also stops automatically when the remote is tilted higher than 45°.
JOBSITE CONFIDENCE & SAFETY
Get the operator away from asphalt fumes With the Dynapac RC360, the operator can keep a distance from the asphalt fumes. The safest way to fulfill local regulations.
Extremely useful in demanding paving situations Whenever precise paving is required, the Dynapac RC360 allows the operator to position himself in the place with the best visibility. The best conditions result in a perfect paving job.
Specifications
MASSES
- Mass (incl. standard screed): 7.0 t
TRACTION
- Paving speed: up to 27 m/min
- Transport speed: 3.3 km/h
ENGINE
- Manufacturer/Model: Deutz TD2.9 L4
- Emissions according to: EU Stage V / EPA Tier 4f
- Rated power: 55.4 kW (75 hp) @2200 rpm
- Electrical system: 2 x 24V, 72 Ah
- Fuel tank capacity: 85 l
ALTERNATIVE ENGINE
- Manufacturer/Model:Deutz TD2.9 L4
- Emissions according to: EU Stage III / EPA Tier 3
- Rated power: 54 kW (73hp) @2200 rpm
- Electrical system: 2 x 24V, 72 Ah
- Fuel tank capacity: 85 l
OPERATION
- Operator console: Slidable left/right
- Platform: Extendable platform
CONVEYOR
- Conveyor type: Splitted conveyor drive with center cover
- Conveyor width: 620 mm
- Conveyor control: Automatic with limit switches
Dimensions
- A. Axle track 1400 mm
- B1. Width, max.2820 mm
- B2. Width, standard 1430 mm
- B3. Width, center of tracks 940 mm
- C1. Track width 200 mm
- H2. Height, transport 2020 mm
- L1. Length, total 4780 mm
- L2. Length, transport, 4380 mm
- L3. Length, hopper, 1605 mm
