Vehicle Mounted Crane

UNIC URU805 Vehicle-Mounted Crane

Max Lifting Capacity (kg)

Max Lifting Capacity (kg)

Max Hydraulic Reach (m)

15.6

Working Pressure (bar)

206

The UNIC URU805 vehicle-mounted crane is designed for light to medium lifting applications on service trucks and utility vehicles. With compact dimensions, reliable lifting performance and remote control operation, it provides an efficient solution for maintenance, construction support and material handling tasks.

UNIC URU805 Vehicle Mounted Crane MIMICO NZ

Compact vehicle mounted crane for service trucks and light lifting applications

The UNIC URU805 vehicle-mounted crane is a compact lifting solution designed for installation on service trucks and light transport vehicles. With a maximum lifting capacity of 8,200 kg and a working radius of up to 15.6 metres, the crane delivers reliable lifting performance while maintaining a compact footprint suited to smaller vehicle setups.

Its five-section telescopic boom provides flexible reach for handling materials, equipment and tools across a range of applications including construction support, utilities work and maintenance operations. The crane is equipped with a hydraulic system designed for smooth operation and precise load control.

With continuous slewing rotation, stabilising outriggers and radio remote control, the URU805 allows operators to safely lift and position loads while maintaining clear visibility and control on site.

UNIC URU805 Vehicle-Mounted Crane Specifications

Slewing Angle (degrees)360 continuous rotation
Working Pressure (bar)206
Height Above Mounting Surface (mm)1938
Width Folded (mm)2260
Crane Length (mm)4950
Slewing Torque (kgm)Not specified
Hydraulic Reach (m)15.6
Control SystemRadio remote control

Warranty: UNIC cranes are supplied with a standard manufacturer warranty. Extended warranty coverage and service support options are available through MIMICO, with full terms provided in the product documentation.

Compact Vehicle Installation

Designed for installation on service trucks and light vehicles where space and payload capacity are limited.

Five Section Telescopic Boom

Provides flexible lifting reach while maintaining a compact crane footprint for transport.

Remote Control Operation

Radio remote control allows operators to safely control lifting operations while maintaining clear visibility of the load.

Stable Outrigger System

Hydraulic stabilisers provide reliable lifting stability across a range of working conditions.

Continuous Slewing

360 degree rotation allows efficient positioning of loads without repositioning the vehicle.

Service and Utility Applications

Well suited to maintenance, utilities and light construction work requiring reliable lifting capability.
