Wheeled Mobile Crusher
Nordwheeler NW1213 Mobile Impact Crusher
Crusher Type
Impact Crusher
Feed Opening
1,300 x 900 mm
Motor Power
295 hp
Portable impact crusher featuring the Nordberg® NP1213M unit. Built for efficient primary reduction in roadworks, aggregates, and recycling.
39T Unit with 1,300 mm Feed and 220 kW Drive
The NW1213 mobile impact crusher is equipped with the Nordberg® NP1213M horizontal shaft impactor, ideal for primary crushing of soft to medium-hard material. It delivers a 1,300 x 900 mm feed opening and a powerful 220 kW motor. With electric drive, integrated Metso IC™ automation, and a compact transport profile, this unit suits civil works, aggregates production, and recycled material processing.
Nordwheeler NW1213 Mobile Impact Crusher Specifications
| Impactor Model | Nordberg NP1213M |
|---|---|
| Feed Opening (mm) | 1300 x 900 |
| Motor Power (hp) | 295 |
| Setting Range (mm) | 20–80 |
| Transport Length (mm) | 14193 |
| Transport Width (mm) | 2990 |
| Transport Height (mm) | 4113 / 4303 |
| Transport Weight (kg) | 39000 / 40000 |
| Bogie Weight (kg) | 22000 / 23000 |
| King Pin Weight (kg) | 21500 / 21000 |
| Feeder Model | TK11-42-2V |
Warranty: MIMICO offers warranty on all material processing equipment, with dynamic options to suit your needs. We also have servicing packages to keep your plants running smoothly. Get in touch with our sales support team to find the right solution for you.
Impactor Unit
Fitted with Nordberg® NP1213M HSI for primary reduction
Feed Capacity
Handles up to 1,300 mm wide material for high-volume work
Transport Setup
Road-mobile chassis with legal width and quick setup
Automation
Includes Metso IC™ control for safe, efficient operation
Drive Power
Electric motor rated at 295 hp for continuous output
Applications
Designed for aggregates, roadworks, and recycling sites
