Compact Track Loader CASE TR270B Compact Track Loader

Compact Track Loader

CASE TR270B Compact Track Loader

Operating Weight

3750 kg

Tipping Load

2449 kg

Operating Cap 50%

1225 kg
The CASE TR270B is a versatile compact track loader designed for landscaping, agriculture, and light construction. With a radial-lift design, powerful breakout force, and low ground pressure, it delivers excellent traction and stability on soft terrain, making it ideal for site preparation, grading, and material handling.

Lightweight Power for Soft Ground

The CASE TR270B is a lightweight yet powerful compact track loader built for New Zealand’s diverse terrain. With a radial-lift design, it delivers exceptional breakout force for digging and grading. The low ground pressure ensures minimal soil disturbance, perfect for landscaping and constuction tasks. A 74hp FPT engine and 2,700lb (1,225kg) rated operating capacity (at 50%) provide strength without excess weight. The maintenance-free Tier 4 Final emissions system boosts efficiency, while the spacious cab and intuitive controls enhance operator comfort. Ideal for tight job sites, the TR270B is the perfect blend of performance and versatility.

CASE TR270B Compact Track Loader Specifications

Operating Weight3,750 kg
Tipping Load2,449 kg
Rated Operating Capacity (50%)1,225 kg
Engine Power74 hp / 55 kW
Lift GeometryRadial
Breakout Force32.3 kN
Track Width320 mm
Hydraulic Flow (Standard)91.5 L/min
Hydraulic Flow (High-Flow)122.6 L/min
Ground Pressure5.9 psi
Height to Bucket Hinge Pin3.18 m
Fuel Tank Capacity73.8 L

Warranty: 1-Year/Unlimited-Hour Full-Coverage or Extended 2-year/2000-Hour Full Coverage

Ultra-Lightweight Design

One of the lightest in its class at 3,750kg, reducing ground disturbance while enhancing fuel efficiency.

Optimised Traction Control

Low ground pressure at just 5.9 psi, making it ideal for soft terrain and minimising site impact.

Industry-Leading Visibility

Large rear window, side lighting, and backup camera ensure maximum jobsite awareness.

Simplified Electro-Hydraulic Controls

Intuitive joystick-based electro-hydraulic controls allow precision movements with minimal effort.

Compact Maneuverability

Shorter overall length and narrow track width improve maneuverability in tight urban job sites.

Maintenance-Free Emissions

Tier 4 Final compliance without a DPF, eliminating downtime for filter regeneration.
