8-Tonne-Metre Knuckleboom Crane

HMF 810K-RC Truck-Mounted Crane

Working Pressure

325 bar

Slewing Angle

400 degrees

Stabiliser Weight

115 kg

The HMF 810K-RC is an 8-tonne-metre knuckleboom crane designed for daily loading, transport work and light construction tasks. It combines strong lifting performance with fast operating speed and remote-controlled precision, making it ideal for operators who need a compact but capable crane.

View Brochure
Call Sales Support
Crane sales 810K-RC truck mounted crane mimico nz
Crane Sales 4020K-RCS TRUCK-MOUNTED CRANE HMF MIMICONZ 8
Crane Sales 4020K-RCS TRUCK-MOUNTED CRANE HMF MIMICONZ 6
Crane Sales 4020K-RCS TRUCK-MOUNTED CRANE HMF MIMICONZ 7
Crane Sales 4020K-RCS TRUCK-MOUNTED CRANE HMF MIMICONZ 4
Crane Sales 4020K-RCS TRUCK-MOUNTED CRANE HMF MIMICONZ 5
Crane Sales 4020K-RCS TRUCK-MOUNTED CRANE HMF MIMICONZ 3
Crane Sales 4020K-RCS TRUCK-MOUNTED CRANE HMF MIMICONZ 2

A strong 8-tm crane built for fast loading and everyday lifting work

The HMF 810K-RC is a versatile crane available in K1 through K4 variants, giving operators several outreach and capacity options for transport work, service vehicles and light construction jobs. It offers full operating speed through the entire working range and delivers a strong lift-to-weight ratio for its size. The crane uses the HMF Single Power Plus link-arm system for fast cycle times, especially when working with grabs. With proportional control, internal hose routing and optional remote systems, the 810K-RC is a reliable choice for efficient everyday lifting.

HMF 810K-RC Truck-Mounted Crane Specifications

Slewing Angle (degrees)400 (K1-K4)
Working Pressure (bar)325
Stabiliser Weight (kg)115
Height Above Mounting Surface (mm)1910
Width Folded (mm)2220
Crane Length (mm)664
Slewing Torque (kgm)840
Hydraulic Reach (m)5.3 - 11
Control SystemProportional valve PVG16, optional Mini or Maxi radio remote

Warranty: HMF cranes come with a standard manufacturer warranty, with extended coverage options available and certain electronic components supported for longer periods.

Download Spec Sheet

Strong lift-to-weight ratio

Provides excellent lifting performance relative to the crane’s compact size.

Single Power Plus link-arm system

Supports high working speed, especially when operating a grab.

Fast operating speed

Delivers full working speed across the entire operating area.

Internal hose routing

Protects hydraulic hoses for reduced wear and improved service life.

Proportional control valve

Gives smooth, predictable control for accurate load handling.

Remote-control ready

Optional Mini or Maxi remote systems let operators work from clear vantage points.
