Compact Track Loader

CASE TR310B Compact Track Loader

Operating Weight

4027 kg

Tipping Load

2810 kg

Operating Cap 50%

1406 kg
Compact yet powerful, the CASE TR310B excels in agriculture, construction, and utilities. Its radial-lift design provides strong digging and pushing power, while the wider tracks enhance flotation on soft ground. Perfect for loading, grading, and site development, it delivers reliable performance in tight working conditions.

Compact Strength, Maximum Traction

Designed for rugged New Zealand job sites, the CASE TR310B offers exceptional stability, traction, and breakout force. A wider 400mm track footprint improves flotation in soft conditions, while the radial-lift arm provides superior digging and pushing power. With a rated operating capacity (at 50%) of 1,406kg, it tackles demanding excavation and site prep work. The 74hp engine ensures smooth power delivery, while electro-hydraulic controls offer precision for attachments. Whether in landscaping, construction, or utilities, the TR310B’s high-flow hydraulics and versatile design make it a go-to machine for high-performance operations.

CASE TR310B Compact Track Loader Specifications

Operating Weight4,027 kg
Tipping Load2,810 kg
Rated Operating Capacity (50%)1,406 kg
Engine Power74 hp / 55 kW
Lift GeometryRadial
Breakout Force38.6 kN
Track Width400 mm
Hydraulic Flow (Standard)91.5 L/min
Hydraulic Flow (High-Flow)122.6 L/min
Ground Pressure5.0 psi
Height to Bucket Hinge Pin3.18 m
Fuel Tank Capacity73.8 L

Warranty: 1-Year/Unlimited-Hour Full-Coverage or Extended 2-year/2000-Hour Full Coverage

Wider Track Base for Stability

400mm wide tracks provide enhanced stability on sloped and muddy conditions.

Optimised Radial Lift Arm

Radial lift delivers maximum pushing power, perfect for ground-engaging applications like grading and digging.

Heavy-Duty Hydraulic System

122.6 L/min high-flow hydraulics power demanding attachments such as rock saws and cold planers.

Dual Speed Travel

Two-speed drive system offers faster travel times, increasing efficiency on larger job sites.

Operator-Focused Cab Design

Pressurised cab with ergonomic controls reduces operator fatigue during long shifts.

Quick-Connect Attachment System

CASE’s Connect-Under-Pressure (CUP) system allows for quick, tool-free hydraulic attachment changes.
