13-Tonne-Metre Knuckleboom Crane

HMF 1330K-RCS Truck-Mounted Crane

Working Pressure

345 bar

Slewing Angle

420 degrees

Stabiliser Weight

170 kg

The HMF 1330K-RCS is a versatile 13-tonne-metre knuckleboom crane designed for a wide range of lifting, loading and transport tasks. It delivers strong lifting power, smooth proportional control and a compact folded profile, making it suitable for operators who need reliable daily lifting across mixed work environments.

Crane-Sales-HMF-1330K-RCS-Truck-mounted-Crane-MIMICO-NZ

A versatile 13-tm crane with excellent lift-to-weight performance

The HMF 1330K-RCS is built to handle a variety of lifting tasks with strong performance and a high lift-to-weight ratio. Available in K1 to K5 variants, it offers excellent reach, fast cycle times and flexible boom geometry, including a 15-degree over-bending joint for working in tight spaces. The crane features the Single Power Plus link-arm system, HDL-d electronic speed adaptation and proportional controls for smooth, controlled movements. With internal hose routing, RCL safety monitoring and a compact folded footprint, the 1330K-RCS is well suited for transport, construction and service work.

HMF 1330K-RCS Truck-Mounted Crane Specifications

Slewing Angle (degrees)420
Working Pressure (bar)345
Stabiliser Weight (kg)170
Height Above Mounting Surface (mm)2135
Width Folded (mm)2500
Crane Length (mm)747
Slewing Torque (kgm)1325
Hydraulic Reach (m)6.1 - 15
Control SystemRCS proportional remote control with PVG32 valve

Warranty: HMF cranes come with a standard manufacturer warranty, with extended coverage options available and certain electronic components supported for longer periods.

High lift-to-weight ratio

Provides strong lifting performance relative to the crane’s low tare weight.

15-degree over-bending geometry

Gives added flexibility in tight work areas, through narrow openings or under low obstacles.

Single Power Plus link-arm system

Supports stable and smooth lifting through the crane’s full range.

Electronic speed adaptation (HDL-d)

Automatically adjusts crane speed to improve control during heavy or precise lifts.

Internal hose routing

Protects hydraulic hoses inside the boom for longer service life.

RCL safety system

Monitors key crane functions to support stable and safe operation.
