30-Tm Knuckleboom Crane

HMF 3220K-RCS Truck-Mounted Crane

Working Pressure

365 bar

Slewing Angle

360 degrees continuous

Stabiliser Weight

370 kg
The HMF 3220K-RCS is a strong and adaptable 30-tonne-metre crane built for general lifting, loading and transport work. It delivers high working speed, smooth proportional control and a compact folded profile, making it well suited for busy transport fleets and mixed lifting jobs across New Zealand.
crane sales hmf 3220k-rcs truck mounted crane mimico nz

A compact 30-tm crane built for fast, flexible lifting on transport fleets

The HMF 3220K-RCS is a versatile knuckleboom crane available in multiple K-variants to suit different outreach and lifting requirements. It provides continuous slewing, strong hydraulic performance and a compact design that maximises truck body space. With the Dual Power Plus link-arm system, operators get stable and consistent lifting across the full working range. The crane is service-friendly with internal hose routing, reduced space requirements and low tare weight. Optional fly-jibs, stabiliser setups and control upgrades allow the crane to be configured for transport operators, construction work, utilities and specialised lifting.

HMF 3220K-RCS Truck-Mounted Crane Specifications

Slewing Angle (degrees)360
Stabiliser Weight (kg)370
Height Above Mounting Surface (mm)2350
Width Folded (mm)2500
Crane Length (mm)1024 - 1130
Slewing Torque (kgm)3800
Stabiliser Beam Range (mm)5600 - 7800
Fly-Jib OptionsJib 600 or Jib 1000
Control SystemRCS proportional remote

Warranty: HMF cranes come with a standard manufacturer warranty, with extended coverage options available and certain electronic components supported for longer periods.

Progressive crane control

Gives smooth, predictable movement for accurate lifting in tight working areas.

Dual Power Plus link-arm system

Maintains lifting strength and stability across the full boom range.

Electronic speed adaptation

Adjusts operating speed automatically to match load and working conditions.

Internal hose routing

Protects hose lines inside the boom for reduced maintenance and longer service life.

RCL safety system

Monitors crane operation and stability to support safe and reliable lifting.

Service-friendly design

Offers easy access for maintenance with reduced downtime and lower ownership costs.
Our team is working on new customer success stories! Check back soon for real-world insights on this product.
